Panasonic WRKT4504E Series - Blind Shutter; Communication Objects

Switching/Blind Actuator
28
4.2 Blind/ Shutter
4.2.1 Communication Objects
Obj.
No
Object name
Function
Size
Datapoint type
Flags
C
R
W
T
U
0
Channel 1/2
Up/Down
Up/Down
1 Bit
[1.8] DPT_UpDown




1
Channel 1/2
Step/Stop
Step/Stop
1 Bit
[1.7] DPT_Step




2
Channel 1/2 Height
%Height
1 Byte
[5.1] DPT_Scaling




3
Channel 1/2 Slat
%Slat
1 Byte
[5.1] DPT_Scaling




4
Channel 1/2
Height/Slat Lock
Lock %height and
%slat
1 Bit
[1.3] DPT_Enable




5
Channel 1/2 Height
Feedback
Height feedback
1 Byte
[5.1] DPT_Scaling




6
Channel 1/2 Slat
Feedback
Slat feedback
1 Byte
[5.1] DPT_Scaling




7-17
Channel 1/2 reserved objects
18-107
Objects for other channels. See below table.
112
Central Up/Down
Blind / Shutter
1 Bit
[1.8] DPT_UpDown




113
114
115
Safety 1
Safety 2
Safety 3
Blind / Shutter
1 Bit
[1.5] DPT_Alarm




