• Off: Does not set the VIQS area.
• Default: Off
[Delete] button
Deletes the VIQS area. Click the button to delete the VIQS area.
[Level]
Configure the difference level in the image quality between specified areas and non-specified areas. The
greater the difference level, the more the image quality of the non-specified area is reduced. This makes it
possible to moderate the image data size.
0 Min./ 1/ 2/ 3/ 4/ 5 Normal/ 6/ 7/ 8/ 9 Max.
• Default: 5 Normal
Stream
[H.264(1)]
Select “On” or “Off” to determine whether or not to activate the VIQS function for the transmitted (H.264(1))
images.
The VIQS (H.264(1)) images can be confirmed with the [Confirm] button.
• Default: Off
[H.264(2)]
Select “On” or “Off” to determine whether or not to activate the VIQS function for the transmitted (H.264(2))
images.
The VIQS (H.264(2)) images can be confirmed with the [Confirm] button.
• Default: Off
[H.264(3)]
Select “On” or “Off” to determine whether or not to activate the VIQS function for the transmitted (H.264(3))
images.
The VIQS (H.264(3)) images can be confirmed with the [Confirm] button.
• Default: Off
[H.264(4)]
Select “On” or “Off” to determine whether or not to activate the VIQS function for the transmitted (H.264(4))
images.
The VIQS (H.264(4)) images can be confirmed with the [Confirm] button.
• Default: Off
IMPORTANT
• After the VIQS setting is set to “On”, the VIQS area may move out of alignment when the JPEG/H.264
“Image capture mode” setting is changed. Make sure to check the VIQS setting after changing the
“Image capture mode” setting.
Note
• Refer to page 103 for setting procedure of the VIQS area.
• When the “H.264 transmission” is set to “Off”, the stream selection cannot be changed.
102 Operating Instructions
11 Configure the settings relating to images and audio [Image/Audio]
