1/60 Fix, 1/100 Fix, 1/120 Fix, 1/250 Fix, 1/500 Fix, 1/1000 Fix, 1/2000 Fix, 1/4000 Fix, 1/10000 Fix
– When a setting other than “1.3 mega pixel [16:9](60fps mode)” is selected for “Image capture mode”:
1/30 Fix, 3/100 Fix, 3/120 Fix, 2/100 Fix, 2/120 Fix, 1/100 Fix, 1/120 Fix, 1/250 Fix, 1/500 Fix, 1/1000
Fix, 1/2000 Fix, 1/4000 Fix, 1/10000 Fix
• Default: Outdoor scene
Note
• When a faster shutter speed is selected (up to 1/10000), it is possible to capture a fast moving object
with less blur.
• When a faster shutter speed is selected, the sensitivity will become lower.
• When “On(High)” or “On(Normal)” is selected for “Super Dynamic(SD)”, “Fix shutter” is not available.
To configure “Fix shutter”, set “Super Dynamic(SD)” to “Off”.
[AGC]
Select a method of gain adjustment from the following.
• On(High)/ On(Mid)/ On(Low): When the luminance of the subject becomes darker, gain will be
automatically increased and screen will become brighter. “High”, “Mid” and “Low” are indications of gain
level.
• Off: Images will be captured with the fixed gain level.
• Default: On(High)
[Maximum shutter]
The maximum shutter time adjusts the storage time of the sensor. The following are available for the recording
duration.
– When the “Image capture mode” is set to “1.3 mega pixel [16:9](60fps mode)” and the “Light control
mode” is set to “Outdoor scene”:
Max. 1/1000s, Max. 1/500s, Max. 1/250s, Max. 1/100s, Max. 1/60s, Max. 1/30s, Max. 2/30s, Max. 4/30s,
Max. 6/30s, Max. 10/30s, Max. 16/30s
– When the “Image capture mode” is set to “1.3 mega pixel [16:9](60fps mode)” and the “Light control
mode” is set to “Indoor scene (50 Hz)”:
Max. 1/100s, Max. 1/60s, Max. 1/30s, Max. 2/30s, Max. 4/30s, Max. 6/30s, Max. 10/30s, Max. 16/30s
– When the “Image capture mode” is set to “1.3 mega pixel [16:9](60fps mode)” and the “Light control
mode” is set to “Indoor scene (60 Hz)”:
Max. 1/120s, Max. 1/60s, Max. 1/30s, Max. 2/30s, Max. 4/30s, Max. 6/30s, Max. 10/30s, Max. 16/30s
– When the “Image capture mode” is set to anything other than “1.3 mega pixel [16:9](60fps mode)” and the
“Light control mode” is set to “Outdoor scene”:
Max. 1/1000s, Max. 1/500s, Max. 1/250s, Max. 1/100s, Max. 2/100s, Max. 1/30s, Max. 2/30s, Max. 4/30s,
Max. 6/30s, Max. 10/30s, Max. 16/30s
– When the “Image capture mode” is set to anything other than“1.3 mega pixel [16:9](60fps mode)” and the
“Light control mode” is set to “Indoor scene (50 Hz)”:
Max. 1/100s, Max. 2/100s, Max. 1/30s, Max. 2/30s, Max. 4/30s, Max. 6/30s, Max. 10/30s, Max. 16/30s
– When the “Image capture mode” is set to anything other than“1.3 mega pixel [16:9](60fps mode)” and the
“Light control mode” is set to “Indoor scene (60 Hz)”:
Max. 1/120s, Max. 2/120s, Max. 1/30s, Max. 2/30s, Max. 4/30s, Max. 6/30s, Max. 10/30s, Max. 16/30s
• Default: Max.1/30s
IMPORTANT
• When a value with an interval longer than “Max.1/30s” (Max.2/30s/ Max.4/30s/ Max.6/30s/ Max.
10/30s/ Max.16/30s) is selected for “Maximum shutter”, the frame rate may become lower. Also, the
maximum exposure time that can be set will change depending on the “Light control mode” setting.
• 1/60s can be set only when 60fps is set.
Operating Instructions 89
11 Configure the settings relating to images and audio [Image/Audio]
