PANAFLEX MILLENNIUM
video assist
8.3 Video outputs
RGB: provides red, green, and blue analog out,
requiring 9 pin D connector to the BNC break-
out cable.
Frameline/FPS: provides both frame line mask
and character generator information.
Video: provides video only (no frame lines,
mask or character generator information).
Panatape: provides an input for the Panatape
in order to display range information in the
video signal.
8.4 Display Options
To display elapsed film in either feet, meters or
frames, press and hold CHAR SIZE and push the
POSITION switch to the right.
To display all information with a black back-
ground, press and hold CHAR SIZE and push the
POSITION switch to the left.
To display the main information screen,
simultaneously push MASK GAIN to the right
and POSITION to the left. Reverse the directions
to turn off the information screen.
