PANAFLEX MILLENNIUM
assembly
3.10 Eyepiece leveler
The eyepiece leveler is used to keep the eyepiece
level as the camera is tilted up and down.
The bottom of the leveler screws into a tapped
hole in the tilt gearbox on the Panahead.
The top incorporates an eyepiece attachment.
Squeeze the two lock tabs together and push
onto the stud located on the rear of the exten-
sion eyepiece. Height adjustments are made by
loosening the lock screws and pushing or
pulling the telescoping sections in and out. To
remove, squeeze the lock tabs together and pull
from the stud.
CAUTION: The eyepiece knuckle must be
unlocked in order to avoid damage during
operation.
