PANAFLEX MILLENNIUM
assembly
3.9 Eyepiece option
The Millennium ships with a short hand held
eyepiece and an extension eyepiece. Both eye-
pieces mount in the same fashion.
The camera ships with a protective cover
mounted in the eyepiece lock. To remove the
cover, depress the button on the lock ring and
rotate counter to the lock arrow. Remove the
cover and place the eyepiece in the lock ring,
making sure the slot in the eyepiece flange is
mated with the key in the lock ring. Rotate the
lock in the direction of the arrow.
If you are mounting the extension eyepiece, you
may find it easier to rotate the knuckle into the
straight up (sky) position and then insert the
eyepiece into the lock ring. The knuckle pivot
lock is a knurled knob located just to the front
of the eyepiece lock ring.
See section 6.1 on the viewfinder for further
information on the eyepieces.
