PANAVISION millennium - General Specifications; Cable Specifications

Focus & T-Stop Motor 7 Pin Lemo
#
1B to 7 Pin Lemo
#
1B
1 Motor +
2 Motor -
3 Ch A
4 +5 VCC
5 Ground
6 Ch B
7ID
Auxiliary 10 Pin Lemo
#
2S to 10 Pin Lemo
#
2S
124V OUT
2 Camera ID
39V OUT - When camera is on
4 Tach OUT
5 Spare
6 Remote Clock Relay
7 Remote Clock Signal IN
8 Ground
9 Shutter Pulse
10 Remote ON/OFF
Zoom Motor 4 Pin Lemo
#
1B to 6 Pin Lemo
#
2S
1 Feedback 3
2 Feedback 4
3 Motor 2
4 Motor 5
Zoom Power 2 Pin Lemo
#
1S to 2 Pin Lemo
#
1S
124V OUT
2 Ground
Power Cable 3 Pin Lemo to 3 Pin male XLR
124VDC
2 Ground
1.1 Cable specifications
1
7
6
25
34
1
67
2
58
9
10
3
4
1
23
4
1
6
5
2
3
4
1
2
1
2
1
2
3
1
2
3
Connector as viewed from the rear with keyway up. Connectors are numbered
counterclockwise in the plug and clockwise in the receptacle.
•
= pin,
º
= socket
