PANAFLEX MILLENNIUM
assembly
3.5 Panalens Lite with video
The Panalens Lite incorporates a small B/W
video camera that can be used as a lens witness
camera when the Millennium is mounted on a
crane or when remote focus is desired. The lens
light mounts to a dovetail located on the motor
cover side of the faceplate, or it can be mount-
ed to a dovetail on the iris rod bracket. A short
power cable is plugged into the 24V DC outlet
on the iris rod bracket or faceplate and into the
lens light. The Panalens Lite incorporates a
dimmer control located on the main body of the
light.
The video camera can be placed in the desired
position by turning the gooseneck. Image
orientation can be adjusted by rotating the con-
trol on the back of light. Focus is accomplished
by turning the lens barrel on the front of the
light.
