PANAFLEX MILLENNIUM
assembly
3.4 On board monitor and bracket
Mount the monitor to the swivel base by screwing
the thumbscrew into one of the threaded inserts
located
on the top or bottom of the monitor.
Insert the stud of the bracket into the receiver
at the top of the iris rod bracket and tighten the
lock lever.
Brightness, color, tint, and contrast controls are
located on the side of the monitor while power
and video in/out are located on the back. If the
image is upside down, slide the invert switch up
or down. This switch is located on the back
next to the video controls.
A sunshade may be attached to the velcro strips
around the front edge of the monitor for
outdoor use.
Monitor operates on 12V to 24V DC power.
