Panduit TDP43ME - Printer Installation

TDP43ME
TDP43ME: PA26305A01_05 Page: 6 of 59 12-2011
1.
Ribbon Supply Shaft
2.
Label Guide (2)
3.
Platen Roller
4.
Label Sensor
1.
Rear Label Slot
2.
Power Switch
3.
Ethernet Socket
4.
USB Port
5.
Parallel Port
6.
Serial Port
7.
AC Adaptor Socket
8.
Wireless Port / Antenna
(optional)
2. Printer Installation
This printer model has the following print modes:
Thermal Transfer (TT)
When printing, ribbon must be installed to transfer the print contents onto the media.
1
2
5
4
6
7
3
8
