Panduit TDP43ME Operation Manual

TDP43ME
TDP43ME: PA26305A01_05 Page: 1 of 59 12-2011
1. Printer
1-1. Printer Accessories
After unpacking, please check the accessories that come with the package, and store appropriately.
 TDP43ME printer
 Power cord
 Switching Power Adaptor
 USB Cable
 Configuration Label
 Ribbon
 Empty Ribbon Core
 Thermal Print Head Cleaning Pen
 TDP43ME Quick Guide
 Easy-Mark™ CD (Labeling Software)
 TDP43ME CD (Drivers, control center &
instruction manual)
 Label Roll Core
 Label Roll Core Side Plates
 Ribbon Rewind Shafts (2)
 Utility Knife
 Warranty Card
1-2. General Specifications
Model
TDP43ME
Resolution
300 dpi (12 dot/mm)
Print Mode
Thermal Transfer
CPU
32 Bit
Memory
4MB Flash, 8MB SDRAM
Print Speed
2 IPS ~ 4 IPS
Print Length
Min 12mm (0.47”),
Max 762mm (30”)
Print Width
105.7mm (4.16”)
Sensor Type
Adjustable Reflective sensor; Fixed transmissive, center aligned
Sensor Detection
Type: Label gap and black mark sensing.
Detection: Label length auto sensing and / or program command setting
Media
Label Roll OD: Max. 4.92” (125mm)
Core Diameter: 1” (25mm), 1.5” (38mm), 3” (76mm)
Width: 1” (25mm) ~ 4.64” (118mm)
Thickness: 0.0025” ~ 0.0098” (0.06~0.25mm)
Ribbon
Length: 981 ft. (300M)
Max. ribbon roll OD: 2.67” (68mm)
Type: transfer ribbons (hybrid, and resin) in widths of:
2.5” to 4.33” (64mm to 110mm)
Core Inner Diameter: 1” (25.4mm)
Printer Language
EZPL Programming Language
Software
DLL & Driver: Microsoft Windows 2000 and XP, Vista (32 & 64 bit);
Microsoft Windows 7 (32 & 64 bit)
Easy-Mark™ Labeling Software

Panduit TDP43ME Specifications

General

Color	Yes
Print technology	-
Maximum resolution	300 x 300 DPI
Maximum print height	- mm
Certification	RoHS
Product color	Black, Grey
Cables included	AC, USB

Weight and Dimensions

Width	226 mm
Height	173 mm
Weight	2720 g
