MACHINE BASICS
12
Embroidery Set Key
1. Back Start - brings design back to start possition
2. Back Offset - brings design back to start possition
3. Set Start - when centering active needle with possition arrows, set start has to be re-set
so you don’t hit your hoop
4. Contour Range Check - traces the outline of the design
* Contour is recommended*
5. Design Range Check - traces in a rectangle or square going to the four outermost cor-
ners of the design
Service Technician Key - For further assistance contact Pantograms at 1.800.872.1555.
