Pantum BM5100FDW Series User Manual

142
4. Make sure the printer body and optional trays are placed correctly, as shown in the figure
below.
5. Plug the power cord into the printer and turn on the power.
After installing the optional tray, you need to update the printer status again (For how to update
the printer status, see “Updating the optional tray status”) .
Note：
• For precautions on loading paper, see “Paper and Print Media”.
• For the type of media to be printed with the optional tray, see the “Paper
Specification”.
• For the installation of optional trays, please refer to the Installation Guide supplied with
the optional trays.

Pantum BM5100FDW Series Specifications

General

Print Technology	Laser
Duplex Printing	Automatic
Connectivity	USB 2.0, Ethernet, Wi-Fi
Max. Monthly Duty Cycle	80, 000 pages
Output Capacity	150 sheets
ADF Capacity	50 sheets
Fax Function	Yes
Memory	512 MB
Functions	Print, copy, scan, fax
Operating System Compatibility	Windows, macOS, Linux
Print Speed	40 ppm
Print Resolution	1200 x 1200 dpi
Mobile Printing	AirPrint, Mopria, Pantum App
Input Capacity	250 sheets
Scanner Type	Flatbed, ADF
Scan Resolution	1200 x 1200 dpi
Copy Speed	40 cpm
Media Types Supported	Plain paper, envelopes, labels
Media Sizes Supported	A4, A5, A6, B5, Letter, Legal
