ParaBody 660 - Page 19

19
0
1
2
345
6
1/2 1/2 1/2 1/2 1/2 1/2
FIGURE 18
STEP 18
• Assemble two ROLLER PADS (37) to the PEC SEAT (5) using two STARLOCK COLLARS (50). See FIGURE 18.
• Pull back the SPRING PIN (51) on the FRONT UPRIGHT (25) and insert the PEC SEAT (5) down to the desired height. Release the
SPRING PIN (51) and allow it to engage into the adjustment holes. Use the 3-PRONG KNOB (61) to tighten the PEC SEAT (5) in
place. See FIGURE 18.
37
50
37
5
50
25
51
