ParaBody 660 - Page 8

8
FIGURE 3
STEP 3
• SECURELY assemble one 4-1/2” PULLEY (43) to the upper flat on the BASE (1) using one 3/8 X 2-1/4” BOLT (86), two 3/8” WASHERS
(91), one 2-7/8” L-BRACKET (44), one 3/8” HEX NUT (108), one SWIVEL SNAP (68) and one 3/8” LOCK NUT (92). See FIGURE 3.
86 3/8 X 2-1/4”
91
108 HEX NUT
1
44
91
43
68
92
