ParaBody cm3 - Step 28: Handle & Strap;Bar Attachment

24
• Assemble two 14-1/2” SEWN HANDLES (19) to the ARM CABLE (31) using two SNAP LINKS (41) as shown in FIGURE 28.
STEP 28:
FIGURE 28
32
41
20
31
41
19
• Assemble two 7-1/2” SEWN HANDLES (20) to the BOOM CABLE (32) using two SNAP LINKS (41) as shown in FIGURE 28.
• Assemble the ANKLE STRAP (26) or the LOW ROW BAR (22) to the LEG CABLE (30) using two SNAP LINKS (41) and one
12-LINK CHAIN (59) as shown in FIGURE 28.
30
59
41
22
26
