Digiplex DGP-848 - 8 - Programming Guide
Keyswitch Programming
Keyswitch Location Module Section 8-digit Serial Number Input# Section Define Assign
Keyswitch
Options
1
_______________ __________
[049]
__/__/__/__/__/__/__/__ __/__/__
[149]
___ ___
14 5 6 7 8
2
_______________ __________
[050]
__/__/__/__/__/__/__/__ __/__/__
[150]
___ ___
14 5 6 7 8
3
_______________ __________
[051]
__/__/__/__/__/__/__/__ __/__/__
[151]
___ ___
14 5 6 7 8
4
_______________ __________
[052]
__/__/__/__/__/__/__/__ __/__/__
[152]
___ ___
14 5 6 7 8
5
_______________ __________
[053]
__/__/__/__/__/__/__/__ __/__/__
[153]
___ ___
14 5 6 7 8
6
_______________ __________
[054]
__/__/__/__/__/__/__/__ __/__/__
[154]
___ ___
14 5 6 7 8
7
_______________ __________
[055]
__/__/__/__/__/__/__/__ __/__/__
[155]
___ ___
14 5 6 7 8
8
_______________ __________
[056]
__/__/__/__/__/__/__/__ __/__/__
[156]
___ ___
14 5 6 7 8
Keyswitch Numbering
Sections [049] to [056] represent keyswitches 1 to 8
respectively. This feature tells the control panel where
the keyswitch is connected and which of the 8
keyswitch locations is assigned to that device.
Enter 3-digit [INPUT NUMBER] of the
Module to which the keyswitch is
connected.
Enter 8-digit [
SERIAL NUMBER] of the
Module to which the keyswitch is
connected.
Keyswitch Parameters
Sections [149] to [156] represent keyswitches 1 to 8
respectively. This feature defines the keyswitch’s
partition assignment and arming method.
Keyswitch Partition Assignment
1- Keyswitch Assigned to Partition 1
2- Keyswitch Assigned to Partition 2
3- Keyswitch Assigned to Partition 3
4- Keyswitch Assigned to Partition 4
Keyswitch Definitions
1- Momentary Keyswitch
2- Maintained Keyswitch
3- Generates Utility Key Event on
Open only
4- Generates Utility Key Event on
Open & Close
Keyswitch Options
[4] Stay/Instant Disarm
[5] On = Arm Only
Off = Arm/Disarm
[6] *Stay Arming
[7] *Force Arming
[8] *Instant Arming
* Select only one. If all are off
keyswitch will regular arm
To Next Page
