DigiplexNE DGP-NE96 - 41 - Programming Guide

Download Memory Key to Control Panel.

1) Insert the Memory Key (PMC-3 ) on to the con tr ol pa ne l’s co nn ecto r labelle d “MEM KEY”.

2) To down load th e co nte nts of t he Memory Key except sections [0 00 1] to [ 009 6] an d [ 050 1] to [0 53 2] , en ter inst aller prog ram min g

mode an d the n e nte r sectio n [ 401 0].

To d own load th e co nte nts of t he Memory Key includi ng sections [0 00 1] to [0096] and [0501] to [ 053 2], enter installer programming

mode an d the n e nte r sectio n [ 4011 ].

3) Wh en th e ke ypad e mits a con firma tion beep, remove th e Memory Key.

Copy Control Panel to Memory Key

1) Insert Memory Key (PMC-3) onto the control panel’s connector labelled “ME M KE Y”. Ensu re th e wr ite prote ct jump er on th e m emo ry

key is on.

2) To copy the con tents to th e M e mo ry Key exc ept sections [0001] to [0 09 6] and [0 50 1] to [0532], e nt er insta lle r prog ramm ing mode ,

the n ent er sect ion [4020].

To copy the con tents to th e M e mo ry Key including sections [0 001 ] to [0 09 6] an d [0 50 1] to [0 53 2], enter section [4021].

3) After the confirmation beep, remove the Me mo r y Key. Remove the Me mo r y K ey ’s jum per if yo u do no t wish to a ccide nta lly ove rwrite

its contents.

AUTOMATIC REPORT CODE PROGRAMMING

When using Contact ID or SIA Reporting formats (section [3070] on pa ge 32 ), de fa ult rep ort code s ca n b e progra mme d a uto matically. Aft er a uto matic

de fau lts ar e set, the y ca n b e ch an ge d a nd the remain ing r e port code s ca n b e se t man ua lly.

SOFTWARE RESET

Performing a software rese t will se t ce rt ain parameters to default values. To do so:

1) Ma ke sur e t he “RE SET” jump er (se e pag e 49) on t he con trol panel is ON.

2) Enter Programming Mode (see page 1).

3) En ter th e 4 - digit [SECTION] corre spon din g to the software reset you wish to perform:

S ection Des cript ion

[40 30]

ALL REPOR T CODES RES ET TO 00

Resets all the report codes from sections [0 201 ] to [0296], [0 70 1] to [0832],

[2 001 ] to [2 19 9] an d [3 90 0] to [3999] to 00.

Sections [4031] to [4037] reset all the report codes in the followin g sect ions t o the

default values f rom the “ Aut omatic Report Co de s List” on pag e 42:

[40 31]

ALL REPOR T CODES RES ET TO FF [0 201 ] to [0 29 6] , [0 701 ] to [0 83 2], [2 001 ] to [2 19 9] & [3 90 0] to [ 399 9]

[40 32]

ZONE ALAR M/ALA RM RESTOR E AND ZONE TA MPER /TA MPER

RES TORE REPORT CODES

[0 201 ] to [0 29 6]

[40 33]

USE R/KEYS WITCH ARMING & DISAR MIN G REPORT CODES [0701] to [0 83 2] , an d [ 20 01] to [2199]

[40 34]

SPEC IAL COD ES [3 900 ] to [3 90 9]

[4035] SPECIAL ARMING/DISARM ING REP ORT CODES [3 910 ] to [3 92 9]

[4036] SPECIAL ALARM REPOR T CODES [3 930 ] to [3 93 9]

[4037] TROUBLE & TROU BL E RES TORE REPORT CODES [3 940 ] to [3 99 9]

S ection Des cript ion

[4040] Entering this section will reset all programmable sections from [0 00 1] to [3999] to factory d efa ult values.

[4041] Entering this section will reset the system master code to 123456.

[4042]

Entering this section will reset all Zone (sections [0001] to [0 19 6] , [ 02 01] to [0296], and sections [ 096 1] to [0984]) p rogra mming t o de fau lt

values.

[4043] Entering this section will reset all access control sections from [2201] to [2 71 2] , exclud ing do or lab els, t o d efa ult va lue s.

[4044] Entering this section will reset all user code sections from [1001] to [1 99 9] and [2 00 1] to [ 21 99] to default values.

[4045] Entering this section will reset all dialer (sections [ 30 51] to [ 30 81]) and control panel (sections [3 020 ] to [3 043 ], an d [3 900] to [3 991 ])

prog r ammin g to d efa ult va lues.

[4046] Entering this section will reset all partition sections from [3 10 1] to [ 382 9], exclu ding part it io n labe ls, to de fau lt valu es.

[4047] Entering this section will reset all PGM (sections from [0901] to [0939]) and all Keyswitch (sect ions [ 050 1] to [ 06 32]) p r ogra mming , as we ll a s
