Paradox Esprit E55 User Manual

8 Programming Guide
Zone Timers
[705] General Zone Options 1
Option OFF ON
[1]
ATZ zone doubling
 Disabled N Enabled
[2]
ATZ wiring options
 Series N Parallel
[3]+[4] Tamper Recognition
[5]
Generate tamper on bypassed zone
N No  Yes
[6]+[7] Supervision Options
[8] N/A N/A N/A
[706] General Zone Options 2
Option OFF ON
[1] N/A N/A N/A
[2]
EOL resistors
 Disabled N Enabled
[3] N/A N/A N/A
[4]
ZX8 ID (Panel + 1) Input 1
 Zone input N Tamper input
[5]
ZX8 ID (Panel + 9) Input 1
 Zone input N Tamper input
[6]
ZX8 ID (Panel + 17) Input 1
 Zone input N Tamper input
Section E55 E65 Data Description (Default 060)
[041] Zone 1 (Z1): (Z1): ____/____/____ (000 to 255) x 10ms Hardwire Zone 1 Speed
[042] Zone 2 (Z2): (Z2): ____/____/____ (000 to 255) x 10ms Hardwire Zone 2 Speed
[043] Zone 3 (Z3): (Z3): ____/____/____ (000 to 255) x 10ms Hardwire Zone 3 Speed
[044] Zone 4 (Z4): (Z4): ____/____/____ (000 to 255) x 10ms Hardwire Zone 4 Speed
[045] Zone 5 (Z1 with ATZ): (Z5): ____/____/____ (000 to 255) x 10ms Hardwire Zone 5 Speed
[046] Zone 6 (Z2 with ATZ): (Z6): ____/____/____ (000 to 255) x 10ms Hardwire Zone 6 Speed
[047] Zone 7 (Z3 with ATZ): (Z7): ____/____/____ (000 to 255) x 10ms Hardwire Zone 7 Speed
[048] Zone 8 (Z4 with ATZ): (Z8): ____/____/____ (000 to 255) x 10ms Hardwire Zone 8 Speed
[049] Zone 9 N/A (Z9): ____/____/____ (000 to 255) x 10ms Hardwire Zone 9 Speed
[050] Zone 10 N/A (Z1 with ATZ): ____/____/____ (000 to 255) x 10ms Hardwire Zone 10 Speed
[051] Zone 11 N/A (Z2 with ATZ): ____/____/____ (000 to 255) x 10ms Hardwire Zone 11 Speed
[052] Zone 12 N/A (Z3 with ATZ): ____/____/____ (000 to 255) x 10ms Hardwire Zone 12 Speed
[053] Zone 13 N/A (Z4 with ATZ): ____/____/____ (000 to 255) x 10ms Hardwire Zone 13 Speed
Keypad Bus Tamper Recognition Options* Keypad / Bus Module Tamper Recognition Options*
[3] [4]
OFF OFF Disabled Disabled
OFF ON Trouble only Trouble only
ON OFF When disarmed:
TROUBLE ONLY
When armed: Follow zone’s alarm type
Trouble only
ON ON When disarmed:
AUDIBLE ALARM
When armed: Follow zone’s alarm type
Audible alarm
* Tamper recognition of keypad / bus module only if section [700] option [7] is enabled.
Keypad Bus Module Supervision Options
[6] [7]
OFF OFF Disabled
OFF ON Trouble only
ON OFF When disarmed:
TROUBLE ONLY
When armed: Follow zone’s alarm type
ON ON When disarmed:
AUDIBLE ALARM
When armed: Follow zone’s alarm type
