Esprit E55 / E65 19
Table 6: IP/GPRS Registration Status (E65 panels only)
Programmable Output Programming
Programmable Output Activation/Deactivation Events
NOTE: PGM 1 (for E55/E65) PGM 2 and 3 (for E65 only)
PGMs 6 to 8 are only available when using an ZX8 or ZX8SP Hardwired Zone Expansion module.
PGMs 9 to 12 are only available when using a PGM4 4-PGM Expansion module.
If a PGM Delay is programmed, the deactivation event can be used as a second activation event (see sections
[281] to [292] on page 24).
[948] ___/___
IP PROFILE (E.G. 01)
[949] IP RECEIVER STATUS
VIEW
STATUS / TO REGISTER, PRESS [ARM]
Main Menu Trouble Sub-Menu Trouble Menu
[1] IP/GPRS module registration status [1] OFF = Unregistered
[1] Slow Flash = Registering...
[1] ON = Registration OK
[2] IP/GPRS module error [7] No IP/GPRS module
[8] Ethernet cable unplugged/GSM no service
[9] No IP address acquired by module/GPRS network trouble
[3] IP/GPRS programming error [7] No IP address (not programmed)
[8] No IP port (not programmed)
[9] No IP account (not programmed)
[10] No Access point name (not programmed - GPRS only)
[4] IP/GPRS registration error [7] Cannot connect
[8] Invalid profile
[9] Invalid format
[10] Account already registered under another MAC address
Register module When all troubles are cleared, press [
ARM] to register module.
Section Event Group # Sub-Group #
Partition # (99 for any
partitions)
Default
[220] PGM 1: Activation Event (____/____) (____/____) (____/____) 00/00/00
[221] Deactivation Event (____/____) (____/____) (____/____) 00/00/00
[222] PGM 2: Activation Event (____/____) (____/____) (____/____) 00/00/00
[223] Deactivation Event (____/____) (____/____) (____/____) 00/00/00
[224] PGM 3: Activation Event (____/____) (____/____) (____/____) 00/00/00
[225] Deactivation Event (____/____) (____/____) (____/____) 00/00/00
[230] PGM 6: Activation Event (____/____) (____/____) (____/____) 00/00/00
[231] Deactivation Event (____/____) (____/____) (____/____) 00/00/00
[232] PGM 7: Activation Event (____/____) (____/____) (____/____) 00/00/00
[233] Deactivation Event (____/____) (____/____) (____/____) 00/00/00
[234] PGM 8: Activation Event (____/____) (____/____) (____/____) 00/00/00
[235] Deactivation Event (____/____) (____/____) (____/____) 00/00/00
[236] PGM 9: Activation Event (____/____) (____/____) (____/____) 00/00/00
[237] Deactivation Event (____/____) (____/____) (____/____) 00/00/00
[238] PGM 10: Activation Event (____/____) (____/____) (____/____) 00/00/00
[239] Deactivation Event (____/____) (____/____) (____/____) 00/00/00
[240] PGM 11: Activation Event (____/____) (____/____) (____/____) 00/00/00
[241] Deactivation Event (____/____) (____/____) (____/____) 00/00/00
[242] PGM 12: Activation Event (____/____) (____/____) (____/____) 00/00/00
[243] Deactivation Event (____/____) (____/____) (____/____) 00/00/00
See Quick Menus on page 41
