26 Programming Guide
NOTE: For reporting code format instructions, see page 24.
NOTE: Refer to Decimal and Hexadecimal Values on page 3.
Ademco Contact ID Report Codes
____/____ Test report ____/____ Installer out
____/____ N/A ____/____ Closing Delinquency
____/____ WinLoad out ____/____ N/A
[878] _____/_____ Disarm with keyswitch
_____/_____
Disarm with keyswitch after
alarm
_____/_____
Alarm cancelled with key-
switch
_____/_____ N/A
CID# Reporting Code Programming
Value
CID# Reporting Code Programming
Value
CID# Reporting Code Program-
ming Value
Medical Alarms - 100 151 Gas detected 26 327 Notification appliance chk.
#4
4E
100 Medical alarm 01 152 Refrigeration 27 System Peripheral Troubles - 330 and 340
101 Pendant transmitter 02 153 Loss of heat 28
330 System peripheral 4F
102 Fail to report in 03 154 Water leakage 29
331 Polling loop open 50
Fire Alarms - 110 155 Foil break 2A 332 Polling loop short 51
110 Fire alarm 04 156 Day trouble 2B 333 Expansion module failure 52
111 Smoke 05 157 Low bottled gas level 2C
334 Repeater failure 53
112 Combustion 06 158 High temperature 2D
335 Local printer paper out 54
113 Water flow 07 159 Low temperature 2E 336 Local printer failure 55
114 Heat 08 161 Loss of air flow 2F 337 Exp. module DC loss 56
115 Pull station 09 162 Carbon monoxide detected 30
338 Exp. module low battery 57
116 Duct 0A
163 Tank level 31 339 Exp. module reset 58
117 Flame 0B Fire Supervisory - 200 and 210 341 Exp. module tamper 59
118 Near alarm 0C 200 Fire supervisory 32 342 Exp. module AC loss 5A
Panic Alarms - 120 201 Low water pressure 33 343 Exp. module self-test fail 5B
120 Panic Alarm 0D 202 Low CO
2
34 344 RF receiver jam detect 5C
121 Duress 0E 203 Gate valve sensor 35 Communication Troubles - 350 and 360
122 Silent 0F 204 Low water level 36 350 Communication 5D
123 Audible 10 205 Pump activated 37 351 Telco 1 fault 5E
124 Duress - Access grated 11 206 Pump failure 38 352 Telco 2 fault 5F
125 Duress - Egress granted 12 System Troubles - 300 and 310 353 Long range radio 60
Burglar Alarms - 130 300 System trouble 39 354 Fail to communicate 61
130 Burglary 13 301 AC loss 3A 355 Loss of radio supervision 62
131 Perimeter 14 302 Low system battery 3B 356 Loss of central polling 63
132 Interior 15
303 RAM checksum bad 3C 357
Long range radio VSWR
prob.
64
133 24-hour 16 304 ROM checksum 3D Protection Loop Troubles - 370
134 Entry/Exit 17 305 System reset 3E 370 Protection loop 65
135 Day/Night 18 306 Panel program changed 3F 371 Protection loop open 66
136 Outdoor 19
307 Self-test failure 40 372 Protection loop short 67
137 Tamper 1A 308 System shutdown 41 373 Fire trouble 68
138 Near alarm 1B 309 Battery test failure 42 374 Exit error alarm 69
139 Intrusion verified 1C 310 Ground fault 43 375 Panic zone trouble 6A
Section Data Description Section Data Description
