Esprit E55 / E65 5
Zone Programming
To program zone definitions, zone partitions and assign options:
Zone Recognition
When expanding zones via ZX8, up to 3 ZX8 modules can be added to the system and are identified by the ZX8 3-position jumpers +1,
+9 and +17.
E55 No ATZ E55 ATZ E65 No ATZ E65 ATZ
Zone 1: Panel Input 1 Zone 1: Panel Input 1A Zone 1: Panel Input 1 Zone 1: Panel Input 1A
Panel Zone 2: Panel Input 2 Zone 2: Panel Input 2A Zone 2: Panel Input 2 Zone 2: Panel Input 2A
Zone 3: Panel Input 3 Zone 3: Panel Input 3A Zone 3: Panel Input 3 Zone 3: Panel Input 3A
Zone 4: Panel Input 4 Panel Zone 4: Panel Input 4A Zone 4: Panel Input 4 Zone 4: Panel Input 4A
Zone 5: Input 1 Zone 5: Panel Input 1B Panel Zone 5: Panel Input 5 Zone 5: Panel Input 5A
Zone 6: Input 2 Zone 6: Panel Input 2B Zone 6: Panel Input 6 Zone 6: Panel Input 6A
ZX8 Zone 7: Input 3 Zone 7: Panel Input 3B Zone 7: Panel Input 7 Zone 7: Panel Input 7A
Jumper Zone 8: Input 4 Zone 8: Panel Input 4B Zone 8: Panel Input 8 Zone 8: Panel Input 8A
Panel + 1 Zone 9: Input 5 Zone 9: Input 1 Zone 9: Panel Input 9 Panel Zone 9: Panel Input 9A
Zone 10: Input 6 Zone 10: Input 2 Zone 10: Input 1 Zone 10: Panel Input 1B
Zone 11: Input 7 ZX8 Zone 11: Input 3 Zone 11: Input 2 Zone 11: Panel Input 2B
Zone 12: Input 8 Jumper Zone 12: Input 4 ZX8 Zone 12: Input 3 Zone 12: Panel Input 3B
Zone 13: Input 1 Panel + 1 Zone 13: Input 5 Jumper Zone 13: Input 4 Zone 13: Panel Input 4B
Zone 14: Input 2 Zone 14: Input 6 Panel + 1 Zone 14: Input 5 Zone 14: Panel Input 5B
ZX8 Zone 15: Input 3 Zone 15: Input 7 Zone 15: Input 6 Zone 15: Panel Input 6B
Jumper Zone 16: Input 4 Zone 16: Input 8 Zone 16: Input 7 Zone 16: Panel Input 7B
Panel + 9 Zone 17: Input 5 Zone 17: Input 1 Zone 17: Input 8 Zone 17: Panel Input 8B
Zone 18: Input 6 Zone 18: Input 2 Zone 18: Input 1 Zone 18: Panel Input 9B
Zone 19: Input 7 ZX8 Zone 19: Input 3 Zone 19: Input 2 Zone 19: Input 1
Zone 20: Input 8 Jumper Zone 20: Input 4 ZX8 Zone 20: Input 3 Zone 20: Input 2
Zone 21: Input 1 Panel + 9 Zone 21: Input 5 Jumper Zone 21: Input 4 ZX8 Zone 21: Input 3
Zone 22: Input 2 Zone 22: Input 6 Panel + 9 Zone 22: Input 5 Jumper Zone 22: Input 4
ZX8 Zone 23: Input 3 Zone 23: Input 7 Zone 23: Input 6 Panel + 1 Zone 23: Input 5
Jumper Zone 24: Input 4 Zone 24: Input 8 Zone 24: Input 7 Zone 24: Input 6
Panel + 17 Zone 25: Input 5 Zone 25: Input 1 Zone 25: Input 8 Zone 25: Input 7
Zone 26: Input 6 Zone 26: Input 2 Zone 26: Input 1 Zone 26: Input 8
Zone 27: Input 7 ZX8 Zone 27: Input 3 Zone 27: Input 2 Zone 27: Input 1
Zone 28: Input 8 Jumper Zone 28: Input 4 ZX8 Zone 28: Input 3 Zone 28: Input 2
Zone 29: N/A Panel + 17 Zone 29: Input 5 Jumper Zone 29: Input 4 ZX8 Zone 29: Input 3
Zone 30: N/A Zone 30: Input 6 Panel + 17 Zone 30: Input 5 Jumper Zone 30: Input 4
Zone 31: N/A Zone 31: Input 7 Zone 31: Input 6 Panel + 9 Zone 31: Input 5
Zone 32: N/A Zone 32: Input 8 Zone 32: Input 7 Zone 32: Input 6
See Quick Menus on page 39
