Paradox Esprit E55 User Manual

10 Programming Guide
Keypad Programming
Keypad Zone Number Assignment
Entry Point Zone Assignment (StayD)
Keypad Input/Output Configuration (K636 V2.0 and higher)
NOTE: When configuring as an output, you must first clear the keypad zone (if assigned).
Step Action Details
1 [
ENTER] + [INSTALLER CODE]
(default: 0000 / 000000)
[ARM] + [STAY] = flash. [MAINTENANCE CODE] may also be used.
2
Press and hold (3sec)
[ARM] + [STAY] = on
3 [
ZONE NUMBER] + [ENTER]* K32LED / K32I = 2 digits: 01 to 32
K10V/H / K636 = 1 digit: 1 to 0(10) (can only assign zones 1-10)
* To erase a keypad zone number, press [CLEAR], then [ENTER].
Step Action Details
1 [
ENTER] + [INSTALLER CODE]
(default: 0000 / 000000)
[ARM] + [STAY] = flash.
2 Press and hold [OFF] (3sec) [ARM] + [STAY] = on
3 [
ZONE NUMBER]* K32LED / K32I = 2 digits: 01 to 32
K10V/H / K636 = 1 digit: 1 to 0(10) (can only assign zones 1-10)
* The first zone you program will be the designated entry point and will flash. Up to three
more path zones can be added; these zones will light up and stay lit.
4 [ENTER] Press [ENTER] to save and exit
Step Action Details
1 [
ENTER] + [INSTALLER CODE]
(default: 0000 / 000000)
[ARM] + [STAY] = flash.
2 Press and hold [
ARM] (3sec) [ARM] + [STAY] = on
3 Option [1] ON = Output switches to ground following system arming (Blue wire 150mA max.).
OFF = Input (Keypad zone input)
4 Option [2] ON = Output N.C.
OFF = Output N.O.
[701] Keypad Options
Option OFF ON
[3]
Confidential mode
N Disabled N Enabled
[4]
To exit confidential mode
N Enter a code N Press a key
[5]
Confidential mode timer
N 2 minutes N 5 seconds
[703] Keypad Options
Option OFF ON
[1]
One-touch regular arming
N Disabled N Enabled
[2]
One-touch stay arming
N Disabled N Enabled
[3]
One-touch sleep arming
N Disabled N Enabled
[4]
One-touch bypass programming
N Disabled N Enabled
