MG6250 Console • User Guide
10 | Chapter 2- Getting Started
MG6250 LCD Screen
The 32-character LCD screen provides visual aids for alarm settings, system information, system troubles, and
more. The following screen illustrates several types of symbols that you may encounter.
Figure 2: MG6250 LCD screen
MG6250 Keypad
Use the keypad to enter user codes or required data, as well select desired menus.
Figure 3: MG6250 keypad
menu
System Ready
Information symbol can indicate:
- There is a trouble in the system
- There is an alarm in memory
- Zones or a zone is currently bypassed
Instructions and/or messages appear here.
Press the action key to access the function
described directly above.
Alarm clock feature enabled
Panic keys
Sends an alarm to your
monitoring station
requesting help from the
police, medical facility, or fire
department.
Main keypad
(digits 0-9)
Phone key
Press once to make a telephone call or
answer an incoming call. Press again to
hang up.
