Paradox MG5050+ User Manual

MG5050+ Programming Guide
13
Zone Recognition
NOTE: For keypad zone programming, see Keypad Programming on page 8.
When expanding zones via ZX8/ZX82, up to three ZX8/ZX82 modules can be added to the system, and they are identified by the ZX8/ZX82 three-position jumpers:
+1, +9, and +17. Table 3 displays zone recognition information for MG5050+ control panels.
NOTE: If a device is assigned to a zone which is already programmed, a wireless zone will overwrite a keypad/hardwire zone and a keypad zone will overwrite a
hardwire zone.
Table 3: Zone recognition information
MG5050+
Type Zone Description
Panel
1Panel input 1
2Panel input 2
3Panel input 3
4Panel input 4
5Panel input 5
ZX8/ZX82 Jumper Panel + 1
6Input 1
7Input 2
8Input 3
9Input 4
10 Input 5
11 Input 6
12 Input 7
13 Input 8
ZX8/ZX82 Jumper Panel + 9
14 Input 1
15 Input 2
16 Input 3
17 Input 4
18 Input 5
19 Input 6
20 Input 7
21 Input 8
ZX8/ZX82 Jumper Panel + 17
22 Input 1
23 Input 2
24 Input 3
25 Input 4
26 Input 5
27 Input 6
28 Input 7
29 Input 8
-
30 -
31 -
32 -

Paradox MG5050+ Specifications

General

Partitions	2
PGMs	16
Wireless Zones	32
StayD Mode	Yes
Number of Zones	32
Wireless	Yes
Remote Control	Yes, via remote controls and app
Power Supply	16.5 V AC
Battery Backup	7Ah
Zones	32 (8 on-board)
