58
MG5050+ Programming Guide
AC Power
Do not use any switch-controlled outlets to power the transformer in order to avoid accidental user AC shut off. Connect the transformer as shown in Figure 1. Use
the below table for appropriate transformer.
Use only a safety approved transformer with rated output voltage of 16.5 Vac and rated power of 40 VA (maximum).
Backup Battery
To provide power during a power loss, connect a 12 Vdc 7 Ah or 4 Ah rechargeable lead acid or gel cell battery. Verify proper polarity as reversed connections will blow the
battery fuse.
Use only safety approved rechargeable battery with rated voltage of 12 Vdc and rated current of 7A maximum.
Battery Test
If the battery is disconnected or if the battery fuse is blown, a No/Low Battery failure will appear in the keypad’s trouble display (See “Trouble Display” on page 55.).
This trouble will also appear if the battery’s capacity is too low or if the voltage drops to 10.5V or lower while the control panel is running on the backup battery.
At 8.5V or lower, the panel shuts down and all outputs close. A battery protection disconnect occurs at 9.1 volts. If output voltage drops below 11.3 volts, a fault
signal is generated.
Demonstration or Emergency System Power-up without an AC Source
To power-up the control panel for demonstration or emergency purposes only, use a standard 12 VDC, 4 Ah/7 Ah backup battery. To power the control panel using
a backup battery:
1. Connect the battery to the control panel's
BATT terminal.
2. Use a wire to short the battery's negative terminal to the panel's
AUX- terminal.
Transformer:
(use only one of the following)
16 VAC 20 VA
Panel DC power supply output rated at: 1.1A
Maximum allowed current supplied by all Auxiliary
outputs:
Max: 700 mA
Battery Charge Currents 500 mA
