MG5050+ Programming Guide
Custom Zone Definitions
With MG5050+ control panels you can create up to four custom zone definition templates (use worksheet 8). Custom zone definition templates (sections [033] to
[036]) will overwrite zone definitions 33 to 36 in table 4 on page 14. Modifications can be made in accordance with table 8 (Permitted zone definitions), on page 15.
Zone Timers
Use the following section to program zone timers for your MG5050+ control panel. Use worksheets 9 and 10 to record your settings.
NOTE: When both ATZ and EOL are enabled, the zone speed should not be set below 300 msec.
Worksheet 8: Custom Zone Definitions
Section Description Disarm Stay Arm Sleep Arm Full Arm
[033] Zone definition template 1 _____/_____ _____/_____ _____/_____ _____/_____
[034] Zone definition template 2 _____/_____ _____/_____ _____/_____ _____/_____
[035] Zone definition template 3 _____/_____ _____/_____ _____/_____ _____/_____
[036] Zone definition template 4 _____/_____ _____/_____ _____/_____ _____/_____
Worksheet 9: Zone Timers for the MG Series
Section Zone MG5050+ Data Description (default: 060)
[041] 1 (Z1) ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 1
[042] 2 (Z2) ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 2
[043] 3 (Z3) ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 3
[044] 4 (Z4) ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 4
[045] 5 (Z5) ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 5
[046] 6 ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 6
[047] 7 ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 7
[048] 8 ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 8
[049] 9 ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 9
[050] 10 ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 10
[051] 11 ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 11
[052] 12 ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 12
[053] 13 ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 13
[054] 14 ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 14
[055] 15 ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 15
[056] 16 ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 16
