Paradox MG5050+ User Manual

18
MG5050+ Programming Guide
Zone Labels
Use worksheet 12 to record your settings when programming zone labels.
Programmable Output Programming
Use the following section to program programmable outputs (PGMs) on your MG5050+ control panel.
Programmable Output Recognition
NOTE: A wireless PGM module can be assigned to any PGM. These modules will work in parallel with the control panel output.
Programmable Output on the K32LCD+
The on-board PGM of the K32LCD+ (not programmable) will follow the arm status of any partition, via any arming method, including StayD.
Worksheet 12: Zone Labels
Section Zone Zone Label Section Zone Zone Label
[181]
1 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[197]
17 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[182]
2 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[198]
18 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[183]
3 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[199]
19 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[184]
4 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[200]
20 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[185]
5 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[201]
21 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[186]
6 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[202]
22 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[187]
7 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[203]
23 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[188]
8 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[204]
24 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[189]
9 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[205]
25 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[190]
10 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[206]
26 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[191]
11 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[207]
27 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[192]
12 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[208]
28 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[193]
13 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[209]
29 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[194]
14 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[210]
30 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[195]
15 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[211]
31 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[196]
16 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[212]
32 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
Table 10: Programmable outputs
PGM PGM Output
Control Panel
MG5050+
1 Control panel output 1 
2 Control panel output 2 
3 Control panel output 3 
4 Control panel output 4 
5 Control panel relay -
6 ZX8/ZX82 ID = 1 output 
7 ZX8/ZX82 ID = 2 output 
8 ZX8/ZX82 ID = 3 output 
9PGM4/PGM82 relay 1 
10 PGM4/PGM82 relay 2 
11 PGM4/PGM82 relay 3 
12 PGM4/PGM82 relay 4 
13 RTX3/RX1 output 1 | PGM82 relay 5 -
14 RTX3/RX1 output 2 | PGM82 relay 6 -
15 RTX3 output 3 | PGM82 relay 7 -
16 RTX3 output 4 | PGM82 relay 8 Optional

Paradox MG5050+ Specifications

General

Partitions	2
PGMs	16
Wireless Zones	32
StayD Mode	Yes
Number of Zones	32
Wireless	Yes
Remote Control	Yes, via remote controls and app
Power Supply	16.5 V AC
Battery Backup	7Ah
Zones	32 (8 on-board)
