Settings
Diagnostics
Show Event(s) Select the events to be displayed on the OLED
Note: Selection do not affect the operation, only the display
Alarm - Alarms are shown
Pre Alarms - Pre Alarms (MW, PIR, Creep) are shown
Trouble - Trouble events are shown
Anti-Mask - Anti-mask events
Restore Settings Restore detector settings that were previously stored by ‘‘Save Settings’’ option
Save Settings Save detector settings
Reset Reset all detector settings to factory defaults
Menu Color Select menu color for better visibility and fun!
Brightness Select the general brightness of indications
Note: The menu is always shown on maximal brightness except for the brightness
screen which demonstrates the chosen brightness
Installation specific settings can be saved and restored if altered. Settings can also be reset to factory defaults, all
with the push of a button. Setting changes occur once the “OK” button is pushed. Changes will not be saved if the
“back” button is pushed.
Diagnostics Menu Action
Test All Tests all detection functions
Shows PIR, MW and Anti-Mask notifications
The blue frame does not appear in this mode
Test PIR Tests PIR detection
Shows PIR detection and Creep Alarm
Test MW Tests and shows MW and MW anti-mask detection
Test Anti-Mask Tests Active IR and MW
The blue frame does not appear in this mode
Test Bus Tests voltage and Digiplex communications
Shows the measured bus voltage
Shows the status of data and clk lines
Ok for valid connection
N/A for no connection or invalid operation
Use the built-in diagnostics to pinpoint troublesome installations. Test the NVX80 detector settings and bus operation.
The Test Bus option will test the bus voltage and Digiplex connection, by checking the status of data and clk lines
reporting no connection or invalid operation.
You can test the PIR, MW and Anti-Mask functionality separately or as a group.
12 NVX80 Version 1.02
