Microwave (MW)
Alarm Condition
Pet Immunity
MW and PIR Both MW and PIR are required for ALARM
Creep Zone detection creates an ALARM, without waiting for MW
Reserved Coming soon
The PIR detection and the microwave detection can be activated alone or in conjunction with the other capabilities.
When setting an output to microwave or PIR only, the relay delays may be as quick as 10 seconds. This should be
noted when performing walk tests, as the relay delay may extend to as long as you keep walking or a maximum of
30 seconds.
Pet Immunity Set for small or large pets
The NVX80’s Pet Immunity can filter out the movement small and large animals, up to 20 kg / 44 lbs in both indoor
and outdoor environments. By ignoring the movement of the pets the detector’s reliability increases.
MW Sensitivity Select sensitivity from 1 (lowest) to 5 (highest)
Push OK to confirm the change
Push Back to cancel any changes
MW AM Distance Control MW anti-mask sensitivity, range of 0.5 m to 2 m
Test MW Test the MW functionality
Shows only MW and MW ‘‘anti-mask’’ indications
The microwave coverage varies depending upon the chosen sensitivity setting. The coverage range is
approximately effective within 10 m – 19 m / 33 ft 3 in – 62 ft 3 in and up to 110 degrees. The greater the sensitivity
setting results in a larger range of coverage.
Sensitivity Setting Range
3 12 m / 39 ft 4 in
4 15 m / 49 ft 2 in
5 17 m / 55 ft 8 in
NVX80 Version 1.02 17
