Paradox NVX80

Passive Infrared Detection with Independent Creep Zone
PIR Sensitivity Select sensitivity from 1 (lowest) to 5 (highest)
The solid bars represent the current settings
The frame represents your selection
Use the Up/Down buttons to toggle through the settings
Push OK to confirm the change
Push Back to cancel any changes
Noise Rejection Control the level of rejection interference
Normal - Indoor, regular and normal
Moderate - Industrial conditions
Harsh - Extreme conditions (bad weather, machinery, etc.)
Pet Immunity Off
Up to 10 kg (22 lbs) - Small Pet
Up to 15 kg (33 lbs) - Medium Pet
Up to 20 kg (44 lbs) - Large Pet
Creep Zone Select Creep Zone sensitivity 1 (lowest) to 5 (highest)
1 for 2.5 m installations
5 for 3.5 m installations
Test PIR Test the PIR functionality
Show only PIR and Creep Zone indications
At an installation height within the suggested range of 2.5 m – 3.5 m / 8 ft 2 in – 11 ft 6 in, infrared detection is
possible up to 17 m / 5 ft 6 in. Detection is at 90 degrees.
The creep zone is exceptionally large. The NVX80 delivers approximately a 180 degree angle covering almost 2 m /
6 ft 7 in in all directions in front of the detector. When the Pet Immunity is activated, the creep zone is neutralized.
Creep alarm as shown in Test and Operation Mode
16 NVX80 Version 1.02
