6 User’s Guide
2.2 KEYPAD INDICATOR LIGHTS
All Spectra LED Keypads include colored lights which
convey your system’s current status. As explained in
Figure 2-1 on page 5, the state of each light represents a
specific condition in your system.
2.3 ZONE DISPLAY
†
The numerical buttons on the 1686V/H Keypads are
designed to communicate the status of the zones in your
system. Each button corresponds to a zone in your
system. If a button’s light is off (extinguished), the
corresponding zone is closed. If a button’s light is on
(illuminated), the corresponding zone is open (i.e. open
door, movement detected, etc.).
2.4 ALARM MEMORY DISPLAY
If an alarm has occurred on a zone, the [MEM] button will
illuminate. All zones where alarms occurred will be
stored in the memory. After disarming the system, press
the [MEM] button to illuminate the buttons corresponding
to the zones that were in alarm (see section 2.3). To exit
the Alarm Memory Display, press the [CLEAR] button.
The system will erase the contents of the Alarm Memory
every time the system is armed.
†patented. See page21.
