Configuration Options
C-8
3160-A2-GB21-80March 1999
Network Interface Configuration Options
Table C-3. Network Interface Configuration Options (1 of 3)
NET Framing: ESF (Factory 1) D4 (Factory 2)
Next D4 ESF Prev
Network Line Framing Format. The framing format to be used on the network interface.
D4 – Configures for the D4 framing format.
ESF – Configures for the Extended Superframe format.
NET Coding: B8ZS (Factory 1) AMI (Factory 2)
Next AMI B8ZS Prev
Network Line Coding Format. The line coding format to be used on the network
interface.
AMI – Configures for the Alternate Mark Inversion coding format.
B8ZS – Configures for the Bipolar 8 Zero Suppression coding format.
LBO: 0.0
Next 0.0 –7.5 –15 –22.5 Prev
Line Build Out. The line build out (LBO) for the signal transmitted to the network (0.0 dB
is the factory default).
ANSI PRM: Disab
Next Enab Disab Prev
Generate ANSI Performance Report Messages. Specifies whether ANSI T1.403
compliant performance report messages (PRMs) are generated.
Enab – Generates and sends ANSI PRMs over the FDL every second.
Disab – Prevents the DSU/CSU from generating ANSI PRMs.
NOTE: This configuration option is only available if the framing format is set to
ESF.
Mgmt Link: Disab
Next Enab Disab Prev
FDL Management Link. Specifies whether Facility Data Link (FDL) is enabled. Selecting
Enab allows SNMP or Telnet traffic to flow over the 4 kbps data link provided by FDL.
Running SNMP or Telnet over FDL requires an end-to-end FDL connection and cannot
be terminated within the network.
Enab – Enables the FDL management link for SNMP or Telnet.
Disab – Disables the FDL management link.
NOTES: – This configuration option is only available if the framing format is set to
ESF.
– This configuration option is not available if EDL is enabled.
– If the local DSU/CSU’s FDL is enabled, the remote DSU/CSU’s FDL
must also be enabled.
