Deactivating the Alarm Relay for Carrier-Mounted
DSU/CSUs
The Alarm Cut-off command forces a deactivation of the alarm relay on the
3000 Series Carrier during an alarm condition. Since this function only affects the
3000 Series Carrier, it is only available for carrier-mounted DSU/CSUs. The alarm
relay function must first be enabled by the Alarm Relay configuration option (refer
to Appendix C,
Configuration Options ).
 Procedure
To deactivate the alarm relay:
1. From the top-level menu screen, press the key until the Ctrl selection
appears on the screen.
2. Select Ctrl.
3. From the Control screen, select ACO.
F1
Control:
ACO Rel LED
F2
F3
4. The Command Complete screen appears.
F1
Alarm Cut-Off:
Command Complete
F2
F3
