Air Flow Diagram
Item
Description
1
Air inlet
2
Coalescing cartridge
3
Connector
4
Tube connector
5
Purifier 1 Φ42x180 (AC/MS) or Purifier 4 Φ42x180 (AC/MS/HP)
6
Filter base
7
Manual drain
8
Safety valve
9
Manual drain outlet
10
Auto drain outlet
11
Air outlet
