Paramina MISTRAL M6-EM User Manual

User Manual - Mistral M6&M8 - 04-2018 from s.n.1882761 edition
.
PARAMINA SA – Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: 0030 210 5575860
Fax: 0030 210 5575868, email: service@paramina.gr - website: www.paramina-compressors.com 43
ITEM
QTY
PART NR.
DESCRIPTION
1a
1
190001760
Crankshaft M8
1b
1
190001761
Crankshaft M6
2
2
110060072
Shaft Ball Bearing
3
1
190001721
Bearing Seat (crankcase front)
4
2
190001701
Hole Lock Ring
5
4
190001281
Tie Rod
6
4
190001291
Tube PL
7
1
190002691
Crankcase
8
1
190001082
Bearing Seat Gasket
9
1
190012701
Con Rod 2
nd
Stage
10
2
192321301
Washer Con Rod
11
2
190012801
Con Rod 1
st
& 3
rd
Stage
12
1
192200822
Washer Crankshaft 8x24
13
1
193106102
Crankshaft Allen Screw M6x10
14
6
192081212
Copper Washer Ø8
15
4
193108202
Allen Screw M8x20
16
4
194200802
Hex Nut M8
17
1
190001691
Shaft Lock Ring
18
1
126356212
Oil Seal
19
1
133365361
Piston Rings Set 2
nd
Stage
20
1
141365361
Piston 2
nd
Stage
21
1
190001111
Piston Pin 2
nd
Stage
22
6
190001271
Lock Ring Piston Pin
23
1
133001521
Piston Rings Set 1
st
Stage
24
1
141001311
Piston 1
st
Stage
25
1
141001312
Crosshead Piston 3
rd
Stage
26
2
190001521
Piston Pin 1
st
& 3
rd
Stage
27
3
190001322
Cylinder Gasket Ø60
28
2
190001351
Cylinder 1
st
&3
rd
Stage
29
1
190000432
Cylinder 2
nd
Stage
30
17
192200602
Washer Ø6
31
4
198000602
Lock Washer Ø6
32
4
197006202
Hex Head Screw M6x20
33
2
192000122
Copper washer 2
nd
Stage Valves Head
34
1
154000430
Inlet Valve 2
nd
Stage
35
1
154000440
Discharge Valve 2
nd
Stage
36
1
127056412
O-Ring Discharge Valve 2
nd
Stage
37
1
190000462
Valve Head 2
nd
Stage
38
6
193108352
Allen Screw M8x35
39
1
127130132
O-Ring Cylinder Guide 3
rd
Stage
40
1
190000172
Cylinder Guide 3
rd
Stage
41
4
194300602
Lock Hex Nut M6
42*
1
*
Piston Rings Set 3
rd
Stage
43*
1
*
Piston 3
rd
Stage
44*
1
*
Piston Sleeve 3
rd
Stage
45*
1
127057122*
O-Ring Piston Sleeve 3
rd
Stage
46
1
154000200
Inlet Valve 3
rd
Stage
