Paramina MISTRAL M6-EM User Manual

User Manual - Mistral M6&M8 - 04-2018 from s.n.1882761 edition
.
PARAMINA SA – Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: 0030 210 5575860
Fax: 0030 210 5575868, email: service@paramina.gr - website: www.paramina-compressors.com 44
47
1
127054362
O-Ring Discharge Valve 3
rd
Stage
48
1
154000280
Discharge Valve 3
rd
Stage
49
1
190000272
Valve Head 3
rd
Stage
50
1
190000302
Top Cover 3
rd
Stage
51
6
193108702
Allen Screw M8x70
52
1
190001381
Gasket down Reed Valve
53
1
154001391
Reed Valve Set 1
st
Stage
54
1
190001401
Gasket up Reed Valve
55
1
190001411
Top Cover 1
st
Stage
56
3
190010252
Socket Top Cover 1
st
Stage
57
1
194000601
Acorn Nut Top Cover 1
st
Stage
58
2
127075742
O-Ring Crankcase
59
1
190001151
Back Cover Crankcase
60
4
127045371
O-Ring Screw Back Cover Crankcase
61
4
197006162
Allen Screw M6x16
62
1
193082502
Set Screw
63
1
194000802
Plug (Allen Screw)
64
1
190001171
Oil Draining Plug
65
1
190001181
Oil sight glass + gasket
66
1
144000072
Coupling D25 G1/2-R1/4 + sealing glue @
the male thread
67
1
120405052
Tee female-female-male 3/8'' + sealing glue
@ the male thread
68
1
116300192
Oil Filling Plug male allen 3/8'' + o-ring
69
1
114501202
Elbow male-male 3/8'' + Teflon @ the up
thread and sealing glue @ the down thread
70
1
190017402
Oil Vapour Exhaust Pipe D21xL80mm 3/8''-
3/8''female (M/T)
70a
1
109000110
Sintered Filter Sponge -Oil Vapour Exhaust
Mistral/Typhoon-
71
1
151203812
Fitting 3/8 BSPT MALE - 1/8 BSPP FEMALE +
sealing glue @ the male thread
72
1
114228052
Quick elbow 1/8'' straight - 6mm pipe
73
1
190001152
Mid crankcase Mistral 8
74
4
193106752
Allen Screw M6x75 Mistral 8
* Supply / Order only as assembly – 3
rd
stage piston complete = 141000001 (replaced
141000000)
