An Overview of the Converter 2-3
512C Series Converter
Understanding the Product Code
The unit is fully identified using a five block alphanumeric code which records how the
Converter was calibrated, and its various settings when despatched from the factory.
The Product Code appears as the “Model No.”. Each block of the Product Code is identified as
below:
Block
No.
Variable Description
1 512C Generic product
2 XX Two numbers specifying the current output, for example:
04 = 4Amp
08 = 8Amp
16 = 16Amp
32 = 32Amp
3 XX Two numbers specifying mechanical package including livery and
mechanical package style, and any option installed over and above the
standard features of the product:
Two numbers Livery
00 Standard Parker SSD Drives livery
01-99 Defined customer liveries
4 XX Two numbers specifying the cover:
IP00 Open Frame
5 XX Two numbers specifying the special options:
00 = Standard
01 - 99 = Documented Special Options
