An Overview of the Converter 2-1
512C Series Converter
AN OVERVIEW OF THE CONVERTER
Component Identification
512C
HEALTH LEDS POTENTIOMETERS SWITCHES
CONTROL TERMINAL BLOCK
TRA NSFORME R
TAPPING LINK
POWER TERMINALS
FIELD TERMINALS
& AUXILIARY SUPPLY
HEATS INK
LEGEND
PLATE
CONTROL
FIXING
POINTS
PCB
PROTECTIVE
GROUND
P1 P8
1
8
ON
1 2 3 LED
LED1 - STALL TRIP
LED2 - POWER ON
LED3 - OVERCURRENT TRIP
P1 - RAMP UP
P2 - RAMP DOWN
P3 - SPEED STABILITY
P4 - CURRENT LIMIT
P5 - IR COMPENSATION
P6 - MINIMUM SPEED
P7 - MAXIMUM SPEED
P8 - ZERO SPEED OFFSET
MAINS OR
AUXILIARY
SUPPLY
AUX MA INS
380/415V
220/240V 110/120V
SELECTOR
OFF
T1 T24
Figure 2-1 View of Component Parts
