3-1 Installing the Converter
512C Series Converter
INSTALLING THE CONVERTER
IMPORTANT: Read Chapter 12: "Certification for the Converter" before installing this unit.
Mechanical Installation
512C
EUROTHERM
DRIVES
A
C
C
B
D
E
F
G
PRODUCT OVERALL DIMENSIONS FIXING CENTRES SIZE SLOT DETAIL
A B C D E F G
512C/04 240mm 160mm 90mm 210mm 148mm M6 15mm 7mm
512C/08 240mm 160mm 90mm 210mm 148mm M6 15mm 7mm
512C/16 240mm 160mm 90mm 210mm 148mm M6 15mm 7mm
512C/32 240mm 160mm 130mm 210mm 148mm M6 15mm 7mm
Table 3.1 Product Dimensions
