Parker 512C Series User Manual

Technical Specifications 11-2
512C Series Converter
Function Rating Cable Size Fuse Isolator Kit Fuse Rating ED Part No.
512C/04 Supply 6A 1.5mm
2
/16AWG LA057605U012 12A fuse CH390123
Motor 4A 1.5mm
2
/16AWG
Ground 1.5mm
2
/16AWG
512C/08 Supply 12A 2.5mm
2
/14AWG LA057605U016 16A fuse CH390163
Motor 8A 2.5mm
2
/14AWG
Ground 2.5mm
2
/14AWG
512C/16 Supply 24A 6mm
2
/10AWG LA057605U032 32A fuse CH390323
Motor 16A 6mm
2
/10AWG
Ground 6mm
2
/10AWG
512C/32 Supply 48A 16mm
2
/6AWG LA057605U050 50A fuse CH390054
Motor 32A 16mm
2
/6AWG
Ground 16mm
2
/6AWG
ALL Field 3A 1.5mm
2
/16AWG LA054664 10A CH230014
Table 11.1 Recommended Cable Sizes.
Note: The cable sizes shown are based on a Form Factor of 1.5 and an overload allowance of
110% (giving a multiplier of 1.65), they are selected for the notional rating of each
controller. Smaller cable may be used if the controller is calibrated at a lower current
level.
Terminal Tightening Torques
Control & Field 0.6 Nm 0.4 lbf-ft 4.5 lbf-in
Power 2.7 Nm 2 lbf-ft 24 lbf-in
Earth 7.1 Nm 5.25 lbf-ft 63 lbf-in
