JOG RES Details
The JOG RES command (Transfer Jog Offset Into Current Position)
clears the Jog Profiler offset of a given axis, and adds the difference
to the Coordinated Moves Profiler (example: JOG RES X). It can also
preload the Jog Profiler offset, and, again, adjusts the Coordinated
Moves Profiler to make up the difference (example: JOG RES X2). In
either case, the Gear and Cam profilers and the Primary and
Secondary setpoints do not change.
The drawing in Figure 13 illustrates JOG RES as it clears the Jog
Profiler.
Figure 13 JOG RES Clears Jog Profiler (JOG RES X)
Making Motion 75
