INSTALLATION AND HOOKUP
LE-Series Oper~to~'s ~anual
2. lUring
A. Motor Connections
i
The LE-Drive is normally supp11~d with a motor complete with
~able and connector. Typically, plugging the motor cable into the
drive is all that is required.
Contact the factory for further details about configuring the LE-
Drive for motors other than provided by the factory.
E. Line Power Connections
120 VAC power is connected via the lEC power connector. The drive
Is supplied with the correct mating power cord. The user's 120VAC
or 220 VAC power system must be a three wire system that include~ an
earth (safety) ground. If the power cord is modified or the user
supplies his own cord, the wires should be conneeted as follows.
U-Drive
120 VAC or 220 VAC LINE
120 VAC or 220 VAC NEUT
AC GND
Wire eolor
Blaek (blue)
lJhite (brovo)
Green (green with yellow)
See Appendix D to eonfigure
C. Indexer Connections
S'I'EP+ and STEP- both must be connected to run the motor.
DlRECTION+ and DlRECTION- 'need only be connected if the motor
need be run bi-directionally. SHUTDOWN+ and SHUTDOWN- must be
connected if the motor is to be shutdown remotely without
powering down the drive. A Comumotor indexer to LE-Drive cable
i.5 supl1ed with the LE-Dri vee The Compumotor indexer to LE-
Drive cable is connected as follows:
Indexer lJire color
Pin ,
--
STEP+
Red
1
ST£P-
Black 14
DlRECTION+ Green
2
DIRECTION-
White
IS
RPS+
Blue
16
RPS-
Brown
17
OV£RDRIVE+
Violet 11
OV£RDRIVE-
Yellow 23
D. Couf1gurat1oD Switches
The LE-Drive ha •• bank of eight switches mounted on its main
printed circuit board. The switches may be accessed by removing
COnlpumotor
p. 5
