DB Series Nitrogen Generator DB5-20 Model
4.5 Settings Menus
Main Menu
Access by pressing [F6] key.
• Select from the following settings:
- High Oxygen Alarms
- Standby
- Maintenance Timer
- Security
- Relay 1 and 2
- Data Logging
• Use the UP and DOWN keys to scroll thru the menu items.
• Press [OK] to select or [ESC] to return to Main Screen
4.6 High Oxygen Alarm Menu and Settings
High Oxygen Alarm Menu
• Use UP and DOWN keys to scroll through menu items
• Press [OK] to select or [ESC] to return to Settings Menu
• Select from the following settings:
- Warning enable, setpoint and delay timer
- Alarm enable, setpoint, and delay timer
- Alarm shutdown – shutdown on High Oxygen Alarm or O2
sensor fault when enabled
High Oxygen Alarm – Enable
• When enabled, high oxygen alarm will occur
• Use UP and DOWN keys to select
• Default is Disabled
• Press [OK] to store or [ESC] to exit without storing
