DB Series Nitrogen Generator DB5-20 Model
7.2 Spare Parts
Model
P&ID Drawing
Number
DB-5-[*]
DB-10-[*]
DB-5-[*]-EC-[W]
DB-10-[*]-EC-[W]
DB-15-[*], DB-20-[*]
DB-5-10-PPM-PCT-FD DB-15-20-PPM-PCT-FD
Filter Elements Part ID Part Number Part Number
Pre-Filter CF101 2/10 0 -18-BX 2/200-35-BX
Final Filter AF 101 2/100 -12-S A 2/20 0-176 -S A
Pilot Valve
Repair Kit Part ID
Part Number Part Number
Solenoid Coil SPV 101-103 P2FCB453 P2FCB453
Manifold
O-Rings
SPV 101-103 P2LBXK84P P2LBXK84P
Pilot Valve
Repair Kit
SPV 101-103 P2LBXSK1 P2LBXSK1
Valve Repair
Kits Part ID
Part Number Part Number
Inlet,
Equalization
and Product
Valve Repair Kit
PV 101-102,
PV 105-108
RKVA037V V RK VA100V V
Exhaust Valve
Repair Kit
PV 103-104 RKVA050VV RK VA100V V
Oxygen Sensor Part ID Part Number Part Number
PPM Sensor AIA 101 02-661 02-661
% Sensor AIA 101 02-662 02-662
7.3 Maintenance Kits
Kit Description Kit Contents
Model
DB-5-[*]
DB-10-[*]
DB-5-[*]-EC-[W]
DB-10-[*]-EC-[W]
DB-15-[*], DB-20-[*]
Part Number Part Number
12-month kit
with % or PPM
analyzer
Replacement elements
and valve repair kits
MK12.D B5 -10 MK12.DB15-20
60-month kit
with %
analyzer
Replacement elements,
valve repair kits and
replacement O2 sensor
MK60.DB5-10-PCT MK60.DB15-20-PCT
60-month kit
with PPM
analyzer
Replacement elements,
valve repair kits and
replacement O2 sensor
MK60.DB5-10-PPM MK60.DB15-20-PPM
