Parker DRD Series User Manual

,
8.3 Technical data
6
DRD 265-1000
Model
Electrical
supply inlet
Compressor
1
MC1(AC/Wc)
Fan motor
3
EV1 (Ac)
Minimum circuit ampacity
MCA(Ac) MCA(Wc)
Maximum protection
device rating
HACR(Ac) HACR(Wc)
Minimum section
validated cable for
electrical
connections
Ø
RLA
(A)
LRA
(A)
RLA
(A) (HP) (A) (A) (A) (A)
230/1/60 8.9 36 0.6 0.13 11.7 - 15 - 12AWG
230/3/60 7.1 38 0.6 0.13 9.4 - 15 - 12AWG
460/3/60 3.3 16 0.6 0.13 4.6 - 10 - 14AWG
DRD 265
230/3/60 7.1 38 0.61 0.59 8.9 - 10 - 12AWG
460/3/60 3.3 20 0.61 0.59 4.8 - 6 - 14AWG
DRD 325
230/3/60 7.1 38 0.61 0.59 8.9 - 10 - 12AWG
460/3/60 3.3 20 0.61 0.59 4.8 - 6 - 14AWG
DRD 400
230/3/60 7.9 45 0.61 0.59 9.9 - 15 - 12AWG
460/3/60 4.2 23 0.61 0.59 5.6 - 10 - 14AWG
DRD 500
230/3/60 10 63 0.61 0.59 12.5 - 15 - 12AWG
460/3/60 5 31 0.61 0.59 7.0 - 10 - 14AWG
DRD 700
230/3/60 13.9 88 2.2 1.07 19.5 17.4 20 20 12AWG
460/3/60 6.4 44 1.25 1.07 9.3 8.0 15 15 12AWG
DRD 800
230/3/60 13.9 88 2.2 1.07 19.5 17.4 20 20 12AWG
460/3/60 6.4 44 1.25 1.07 9.3 8.0 15 15 12AWG
DRD 1000
230/3/60 - - - - - - - - -
460/3/60 7.9 50 1.25 1.07 11.1 9.9 15 15 12AWG
Calibration values Hot gas valve
9-HGV
Fan pressure Switch
12-PV
High pressure switch
15-HP
Low pressure switch
6-LP
Water pressostatic
valve
22-WPV
Air - Side Max
Working Pressure
DRD265-1000
66.7 - 69.6 PSIg
4.6 - 4.8 barg
ON: 261 PSIg
OFF: 203 PSIg
ON: 18 bar
OFF: 14 bar
406 PSIg
28 barg
21.8 - 36.3 PSIg
1.5 - 2.5 barg
232 PSIg
16 barg
203 PSIg(*)
14 bar(*)
(*) Models for Canada with CRN, max working pressure is:
174 PSIg (12 bar).
