Parker P1D Series Operating Information

Parker Hannifin Corporation
Pneumatic Division
Richland, Michigan
www.parker.com/pneumatics
B75
Catalog PDN1000-3US
Parker Pneumatic
B
Tie Rod Cylinders
Actuator Products
3MA
Series
4MA/4ML
Series
3MAJ/4MAJ
Series
4MNR
Series
P1D
Series
According to CETOP RP 107 P, VDMA 24 562, AFNOR
Bore
size
mm
CK
H9
mm
S5
H13
mm
K1
JS14
mm K2
G1
JS14
mm
G2
JS14
mm
EM
mm
G3
mm
CA
JS15
mm
H6
mm
R1
mm
Weight
kg Part number
32 10 6.6 38 51 21 18 25.5 31 32 8 10.0 0.06 P1C-4KMD
40 12 6.6 41 54 24 22 27.0 35 36 10 11.0 0.08 P1C-4LMD
50 12 9.0 50 65 33 30 31.0 45 45 12 13.0 0.15 P1C-4MMD
63 16 9.0 52 67 37 35 39.0 50 50 12 15.0 0.20 P1C-4NMD
80 16 11.0 66 86 47 40 49.0 60 63 14 15.0 0.33 P1C-4PMD
100 20 11.0 76 96 55 50 59.0 70 71 15 19.0 0.49 P1C-4QMD
125 25 14.0 94 124 70 60 69.0 90 90 20 22.5 1.02 P1C-4RMD
160 30 14.0 118 156 97 89 88.5 126 115 25 31.0 C.F. L075480160
200 30 16.0 122 162 105 89 88.5 130 135 30 31.0 C.F. L075480200
C.F. = Consult Factory
G1
ØCK
CA
G2
G3
R1
H6
K2
K1
ØS5
EM
According to VDMA 24 562, AFNOR
Bore
size
mm
E
mm
B1
mm
B2
mm
EN
mm
R1
mm
R2
mm
FL
mm
I2
mm
L
mm
CN
H7
mm
XD
mm Z
Weight
kg Part number
32 45 10.5 – 14 16 – 22 5.5 12 10 142 4° 0.08 P1C-4KMSA
40 52 12.0 – 16 18 – 25 5.5 15 12 160 4° 0.11 P1C-4LMSA
50 65 15.0 51 21 21 19 27 6.5 15 16 170 4° 0.20 P1C-4MMSA
63 75 15.0 – 21 23 – 32 6.5 20 16 190 4° 0.27 P1C-4NMSA
80 95 18.0 – 25 29 – 36 10.0 20 20 210 4° 0.52 P1C-4PMSA
100 115 18.0 – 25 31 – 41 10.0 25 20 230 4° 0.72 P1C-4QMSA
125 140 25.0 – 37 40 – 50 10.0 30 30 275 4° 1.53 P1C-4RMSA
160 177 30.0 – 43 44 41 55 4.0 41 35 315 16° C.F. L075420160
200 214 30.0 – 43 48 42 60 8.0 42 35 335 16° C.F. L075420200
S = Stroke length C.F. = Consult Factory
XD+S
ØCN
R1
R2
L
B2
B1
E
EN
I2
FL
Z
Z
Intended for exible mounting of cylinder. The pivot
bracket can be combined with clevis bracket MP2.
Materials:
Pivot bracket: Surface-treated aluminium, black
Bearing: Sintered oil-bronze bushing
Intended for use together with clevis bracket GA
Materials:
Bracket: Surface-treated aluminium, black
(Cast iron for 160-200mm bores)
Swivel bearing acc. to DIN 648K: Hardened steel
Supplied complete with mounting screws for
attachment to cylinder.
Pivot Bracket with Rigid Bearing
Swivel Eye Bracket – MP6
Actuator Products – Tie Rod Cylinders
P1D Series
