Parker P1D Series Operating Information

Parker Hannifin Corporation
Pneumatic Division
Richland, Michigan
www.parker.com/pneumatics
B72
Catalog PDN1000-3US
Parker Pneumatic
B
Tie Rod Cylinders Actuator Products
3MA
Series
4MA/4ML
Series
3MAJ/4MAJ
Series
4MNR
Series
P1D
Series
P1D Tie-Rod Version (160-200mm)
E
E
TG
TG
DD
B
MM
VE
G
BG
ZJ + Stroke
EE
G
VD
B
PJ + Stroke
Y
WH
VD
Rod End #1 Rod End #2
MM
AM
VE G
ZJ + Stroke
EE
WH
Y
ZM + (2 x Stroke)
PJ + Stroke
G VE
WH + Stroke
AM
MM
B
d11
mm
EE
Bore
size
AM
mm
BG
mm DD
E
mm BSPP
3
NPTF/
BSPT
G
mm
MM
mm
TG
mm
VD
mm
VE
mm
WH
mm
Y
mm
PJ1
mm
ZJ1
mm
ZM2
mm
160 72 65 24 M16 177 G3/4 3/4 54 40 140 6 56 80 105 130 260 340
200 72 75 24 M16 214 G3/4 3/4 54 40 175 6 56 95 120 130 275 370
1
Add stroke
2
Add 2× stroke
3
ISO 1179-1 with ISO 228-1 threads
Double Rod Cylinders
Double rod option is available on Mounting Styles MX0, MS1,
MF1, MF2 and MT4.
For double rod cylinders, it is assumed that the rod number
and rod end are the same for both piston rods. On a double
rod cylinder where the two rod ends are different, use a
rod end of ‘3’ and be sure to clearly state which rod end is
to be assembled at which end.
Actuator Products – Tie Rod Cylinders
P1D Series
