Catalog 0700P-5/USA
Ordering Information
Ordering Information
Port Size
2 1/4"
4 1/2"
Pressure Range
Z 0-2 bar (0-29 PSI)
D 0-10 bar (0-145 PSI)
Power Supply
2 24 Volts
Control Signal
V 0-10 V *
Output
D Digital, PNP
M 4 to 20 mA Fixed
N* NPN or 0 to 10V
P* PNP or 0 to 10V
Input Connector
1 M12 (4-Pin)
Port Type
1* G Thread (BSP)
Female
9 NPT Female
* Factory setting is
0-10 V control
signal. 4-20 mA
control signal
available via
parameter 4 on
keypad.
Version
A Bottom Exhaust
B* Side Exhaust
F* Food Version
E*
†
Forced Exhaust
Pressure Power Control Input Eng.
Port Type Port Size Version Range Supply Signal Output Connector Level
P3 HPA 9 2 A D 2 V D 1 A
* Available on Request.
* Selectably by means of
parameter 6.
HPA 1/4"
KNA 1/2"
* Available on Request.
† When the supply voltage is lost, the unit
will automatically exhaust the regulated
pressure to 0 PSIA.
1) Digital PNP output only, no analog
output selectable.
2) Digital PNP and analog 0 - 10V outputs
selectable by means of Parameter 6.
(Factory default 0-10V)
3) Digital NPN and analog 0 - 10V outputs
selectable by means of Parameter 6.
(Factory default 0-10V)
4) Analog 4-20mA output only.
Note: On all Analog outputs, the F.S.
value can be adjusted by means of
Parameter 8.
P3HPA / P3KNA Kits
Seal Kit (Valve Seat, Cover Seal) ..............................3538200
Valve Kit (2 Valves, Screws, Cover Seal) ..................3538100
Cable (M12, 4-Pin Female Connection
with 2m Cable) ..............................................CB-M12-4P-2M
“P3HPA” / “P3KNA” Series
Electronic Proportional Regulators
Note: P3KNA modular mounting for use
with Moduflex European FRL only.
(Revised 07-09-08)
