USB Data Link Adapter 13
Using the USB-DLA
5. Using the USB-DLA
5.1. Plug in the USB cable
Connect the DLA to your computer using the USB cable provided. Plug the A-type
receptacle into the back of your computer (1), and the B-type receptacle into the
DLA (2). You should hear a Windows alert every time the DLA is connected or
disconnected.
i
INFORMATION
The DLA is considered a high current device because it draws more than 100mA
when operating. The unit must be plugged directly into your PC, or into a powered
USB hub. It will not operate if plugged into an un-powered USB hub.
Figure 6: Connect DLA to PC
